COMPACTORS AND CARTS

  • Marine Green Compactor
  • Segregate and compact solid waste material into wheeled carts for recycling and convenience
  • Enclosed structure for compaction operations
  • Carts provided with positive lock in restraint system, secures cart into compactor or to bulkhead
  • Cart door with latch engineered for gradual release
  • No ramps needed for placement and removal of carts
  • No compaction force on the wheels
  • Bags manufactured to a 5:1 safety ratio
  • ABS Approved
  • Meets and exceeds International MARPOL 73/78 Annex V
  • Patent pending

SPECS

  Model MG2 Model MG5 Model MG10 Model MG15
Capacity 7 ft³ 19 ft³ 45 ft³ 58 ft³
Compactor Unit Height 76'' 89'' 107'' 120''
Cart Height 28'' 43'' 56'' 60''
Compactor Unit Height 32'' 43'' 54'' 57''
Cart Height 25'' 40'' 48'' 46''
Compactor Unit Height 24'' 44'' 46'' 49''
Cart Height 22'' 43'' 44'' 47''
Compactor Unit Height 6 ft² 13 ft² 17 ft² 19 ft²
Cart Height 4 ft² 11.6 ft² 14 ft² 15 ft²
Compactor Unit Height 435 lbs 800 lbs 940 lbs 1,100 lbs
Cart Height 86 lbs 86 lbs 86 lbs 86 lbs
Compaction Force 10,000 lbs 14,000 lbs 30,000 lbs 30,000 lbs
Bag Model B-600-01-07-W3 B-20M-01-07-W3.5 B-4000-01-07-W4.5-K B-5000-01-07-W5
Bag Swl 650 lbs 600 lbs 2,000 lbs 2,200 lbs

Note: All measurements are rounded up to the nearest whole unit or decimal.
